AQSync Solar Trailer

The AQSync paired with a custom WancoĀ® solar trailer allows you to make FEM-quality measurements anywhere. With no need for expensive infrastructure, you can deploy quickly and easily. This system can provide your community with immediate access to critical air pollution data in emergencies or during wild fire smoke events.

  • Ambient ozone measurements from 2B Tech’s FEM Model 108-L Ozone Monitor (EQOA-0914-218)
  • Ambient NOx measurements from 2B Tech’s FEM Model 405 nm NO2/NO/NOx Monitor (EQNA-0217-243)
  • Optical particle counter with sheath flow and heated inlet for FEM-quality PM1, PM2.5, and PM10 measurements
  • Optional Methane and BTEX modules available. Please reach out to our Sales Team ([email protected]) for more information
  • System power is supplied by batteries, continuously and automatically charged by the solar panels
Product Inquiry
Overview
Specifications
Downloads
Support
Case Studies
Product Inquiry

Overview

Measure what you want, where you want, with the AQSync and Wanco’s custom solar trailer

Customizable AQSync module choices include:
  • 2B Techā€™s FEM instruments for O3, NO2, and NO
  • Met One Instrument’s Optical Particle Counter with sheath flow and heated inlet for FEM-quality PM1, PM2.5, and PM10
  • NDIR absorbance instrument for CO2
  • Photoionization sensor for total VOCs
  • Amperometry sensor for CO
  • Weather data including sonic anemometer for wind speed and wind direction
  • Optional modules for Methane and BTEX available. Please reach out to our Sales Team ([email protected]) for more information



Wanco’s custom solar trailer includes:
  • Telescoping tower with manual winch
  • Integrated AQSync support bracket
  • Locking hitch pins allow you to easily attach and remove AQSyncĀ
  • 730 W solar array, 400 Ah battery bank in high-security battery box
  • Smart MPPT solar charge controller for outstanding power efficiency



AQSync Features

  • Rugged NEMA 4X IP67 enclosure for outdoor installation
  • Real-time data uploading to the cloud using either cellular or wifi connectivity
  • Online Data Portal to view AQSync data remotely
  • Touch-screen interface
  • Remote-control of the AQSync via the web

Wanco Solar Trailer Features

  • Telescoping tower with manual
  • Integrated AQSync support bracket
  • Easily attach/remove AQSync, secured to tower with locking hitch pins
  • 730 W solar array
  • 400 Ah battery bank in high-security battery box
  • Smart MPPT solar charge controller for outstanding power efficiency



Contact us at [email protected] to discuss your application and customizable options for this system

Contact us at [email protected] to discuss your application and customizable options for this system

  • Ellenburg, J.A., Williford, C.J., Rodriguez, S.L., Andersen, P.C., Turnipseed, A.A., Ennis, C.A., Basman, K.A., Hatz, J.M., Prince, J.C., Meyers, D.H., Kopala, D.J., Samon, M.J., Jaspers, K.J., Lanham, B.J., Carpenter, B.J. and Birks, J.W. (2019) Global Ozone (GO3) Project and AQTreks: Use of evolving technologies by students and citizen scientists to monitor air pollutants,Ā Atmospheric Environment: X,Ā 4, 100048. 2BTechLink

Specifications

Spec Sheet
Instrument/Sensor Specifications (per manufacturer)
Ozone (O3)



Measurement Method:Ā UV Absorbance at 254 nm

Instrument:Ā 2B Technologies Model 108-L (FEM)

Linear Range: 0-1,000 ppb (0-1 ppm)

Precision:Ā 1.5 ppb or 2% of reading for 10-s avg

Accuracy:Ā 1.5 ppb or 2% of reading

Response Time:Ā 4 s for 2-s avg, 20 s for 10-s avg

 Nitrogen Dioxide (NO2)



Measurement Method:Ā Direct Absorbance at 405 nm

Instrument:Ā Based on 2B Tech Model 405 nm NO2/NO/NOxĀ Monitor (FEM for NO2)

Linear Range:Ā 0-10,000 ppb

Precision:Ā 0.5 ppb

Accuracy:Ā 2 ppb or 2% or reading

Response TimeĀ 20 s
Nitric Oxide (NO)



Measurement Method:Ā Oxidation to NO2Ā with O3
followed by Absorbance of NO2Ā at 405 nm

Instrument:Ā 2B Tech Model 405 nm NO2/NO/NOxĀ Monitor

Linear Range:Ā 0-2,000 ppb

Precision:Ā 0.5 ppb

Accuracy:Ā 2 ppb or 2% of reading

Response Time:Ā 20 s

 Particulate Matter (PM1, PM2.5, PM10)



Measurement Method:Ā Optical Particle Counter, right angle light scatter detection with sheath flow and heated inlet

Instrument:Ā Met One Instruments Model 83214

Range:Ā 0-320,000 particles per liter

Minimum Particle Size:Ā 0.3 Ī¼m

Accuracy:Ā 10%

Response Time:Ā minimum 1 s
Carbon Dioxide (CO2)



Measurement Method:Ā Non Dispersive Infrared (NDIR) Absorbance with Auto-Zeroing

Instrument:Ā PP Systems CO2Ā Gas Analyzer,

Model SBA-5

Linear Range:Ā 0-1,000 ppm

Precision:Ā 1 ppm

Accuracy:Ā 5 ppm

Response Time:Ā 10 s

 Carbon Monoxide (CO)



Measurement Method:Ā Amperometry

Linear Range:Ā 0-50 ppm

Sensor:Ā Alphasense CO-A4

Precision:Ā 0.02 ppm

Accuracy:Ā 0.1 ppm

Response Time:Ā 20 s
Total VOCs



Measurement Method:Ā Photoionization Detector

Sensor:Ā ION Science Mini-PID2 HS

Measurement Range:Ā 0 to 3 ppm

Sensitivity:Ā > 600 mV per ppm

Minimum Detection Limit:Ā 0.5 ppb

Response Time:Ā < 12 s

 Methane



Measurement Method:Ā Tunable-Diode Laser

Sensor:Ā Axetris LGD Compact-A CH4

Measurement Range:Ā 0 to 100 ppm

Precision:Ā up to 100 ppm, < 0.8 ppm

Resolution:Ā 0.01 ppm

Sampling Rate:Ā 2 Hz
Speciated BTEX

Ā

Measurement method: microGC

Sensor: PyxisGC BTEX

Carrier gas: Ambient Air, <10 sccm

Sampling: Sample Flow Rate 250 – 450 sccm

Detector: High-sensitivity PID – Photo Ionization Detector (10.6 eV)

Analytical performance: [0.5 ā€“ 80] Ī¼g/m3, benzene with 10 min analysis cycles ā€œSmart Cityā€ configuration [1 ā€“ 160] Ī¼g/m3, benzene with 10 min analysis cycles ā€œFence Lineā€ configuration

Lower detection limit: <0.2 Ī¼g/m3 (0.05ppb) benzene

 Ā









Spec Sheet 2
Weather Station Specifications (per manufacturer)
Gill Instruments MaxiMet 500GMX
 Range Accuracy
Temperature -40 to +70 Ā°C Ā±0.3 Ā°C (at 20 Ā°C)
Pressure 300 ā€“ 1100 hPa Ā±0.5 hPa (at 25 Ā°C)
Relative Humidity 0 ā€“ 100% RH Ā±2 %RH (10 to 90 %RH)
Wind Speed
(2-D Sonic Anemometry)		 0.01-60 m/s (134 MPH) Ā±2% (0-30 m/s)
Ā±3% ( >30 m/s)
Wind Direction
(2-D Sonic Anemometry)		 0-360 degrees azimuth Ā±3 degrees (to 40 m/s)
Ā±5 degrees (40-60 m/s)
Spec Sheet 3
System Specifications
Weight 54.7 lb, 24.9 kg
(varies with modules chosen)
Size 25.5 x 25.5 x 10.3 in (65 x 65 x 26.2 cm); height with weather station is 49 in (124.5 cm)
Power 35-60 watt (53-78 watt max during warmup)
(varies with modules chosen)
Data Transmission Cellular or WiFi to the Cloud; Ethernet; Modbus (TCP); SD card
Sample Flow Rate ~4 L/min
(varies with modules chosen)
